NOVA ORION 18” DVR LATHE (SKU 55250)
**New orders are due in late February 2023
This lathe combines the best features of larger lathes – power, capacity and capability with state-of-the-art technology to make your turning more efficient, fun and safer. Great for those who need all the workshop space they can get. The lathe can be configured with a compact footprint or using the bed extension (included as standard) the Orion can be made longer to suit longer projects as needed.
The swivel head and articulated Outrigger Accessory, together with the flexible bed configuration, means that even when turning large bowls (29”), you are still turning in the same compact area. With no pulleys or belts to vibrate, the Award-Winning DVR Direct Drive Motor powered by STRIATECH is incredibly smooth and delivers intelligent control to your turning experience.
NOVA ORION 18″ DVR LATHE (SKU 55250) SPECIFICATIONS
- Bowl turning capacity:
18″/457mm inboard
29”/736mm outboard (using optional outrigger accessory expected to be released in 2021) - Spindle Thread: 1 1/4″ x 8TPI RH (USA, Canada, Australasia)
M33 x 3.5 RH (Europe, UK) - Between Centers: Standard 45.25”/ 1149.35mm with included extra Bed Extension
or 22.75”/ 577.85mm in the compact configuration - HP: 1.75 HP 110/2HP 220V DVR Direct Drive Motor
- 100 – 5,000 RPM continual Variable Speed with dial for precise and fast speed
- Self-Ejecting 2MT Hollow Tailstock
- Power to Turn and Burn
More power/torque than any competitive 18″ lathe - Incredible Variable Speed Range – 100 RPM – 5,000 RPM
- 8 Favorite Speeds
- Electronic Auto Braking
- Speed Selection Chart
- 8 Favorite Speed Settings
ORDER CODES:
55250: 1 1/4″ Spindle 115v (USA)
55252: M33 Spindle 230v (Europe)
55251: 1 1/4″ Spindle 230v (NZ / Australia)
NOVA ORION 18″ DVR LATHE (SKU 55250) WARRANTY:
* 5 Year Warranty on Parts and Components
*2 Year Warranty on Motor and Electronics
* Restrictions apply
